Size: 158 * 150 * 58
Weight: 338g (without battery)
Transmission frequency: 2.400GHZ-2.7GHZ
Transmitter Module: Four in One High Frequency Module (CC2500 CYRF6936 A7105 NRF2401)
Transmit power: maximum 22dbm (transmit power adjustable)
Antenna gain: 2db (detachable antenna, easy modification)
Working current: 88Ma@8.4V
Working voltage: DC4.5-DC18V (factory with 4 * AA battery box, lithium battery recommended 2s balanced head line, batteries not included)
Remote control distance:> 2km @ 22dbm
Open source firmware:
Number of channels: up to 12 channels (depending on the receiver)
Display: 2.42-inch OLED display, 128 * 64 resolution
Rocker way: non-contact 3D space vector Hall joystick
JR/FrSKY compatible module bay on rear side
Upgrade method: USB online upgrade
Support Protocols:
Walkera full range
DSM2/X full range
Flysky and Flysky 2A
FrSKY
FUTABA s-fhss full range
WL Toy series, Hubsan series, Esky series and many more (Currently a total of more than 40 supported protocols)
Uses open source software with continued support and development, adding new protocols regularly.
Simulator mode: 3.5mm standard ppm output
USB output.
T8SG Plus improvements.
1.) All new tooling design gives a unique appearance and ergonomic feel.
2.) Two addition top switches added.
3.) Improved switch quality on all switches for better reliability and quality feel.
4.) All new HALL SENSOR Gimbal design gives finer accuracy and crisp response.
5.) JR module bay added for third party RF Modules
6.) Front dials changed to Side scroll wheels for improved usability.
7.) External USB port for added convenience.
8.) 2.7” Backlit OLED Display
9.) Added AA Battery box for easy battery installation (2s Lipo optional)
10.) Improved on off switch with dual LED Status indicators.
11.) Improved shipping box, high strength with high end appearance.
12.) Quick start guide included.
